Description

Key Features:

• Extremely wide clamping range for rims of 4″ – 58″ without extensions
• High bead breaking force of up to 38 kN
• Rugged design for intensive handling of wheels of up to 2000 kg and 2.5 m diameter
• Lowering of chuck to 350 mm to facilitate accommodation of rims of small diameter
• Long jaws to accommodate rims of high offset
• Accommodation of rim flanges of up to 40 mm thick
• Control unit ergonomically fitted on boom on machine
• 2 Chuck speeds to be preset by switch

Technical Features:

Clamping range (inch) 4 – 58
Wheel width max. (inch) 59
Wheel diameter max. (mm) 2500
Wheel weight max. (kg) 2000
Bead breaker force (kN) 38
Chuck speed (rpm) 4/8
Torque max. (Nm) 3100
Power supply 400 VAC 3ph 50Hz
Width (mm) 2990
Depth (mm) 2100
Height (mm) 2025
Noise level (dB (A)) < 70
Weight (kg) 1450
